AeroPel™ NPL (Nanocomposite Protective Layer) APC400 is an advanced, superhydrophobic surface treatment for aircraft deicing currently in development that will reduce ice adhesion strength.

A small aircraft with the body removed from the engine for maintenance

01

Aircraft icing disrupts operations

When ice forms on aircraft surfaces, it can disrupt the airflow over the wings and tail, leading to a loss of lift and potentially causing dangerous in-flight conditions. Ice accumulation can also increase the weight of the aircraft, further compromising its performance and safety. In addition to safety concerns, icing can cause operational disruptions, resulting in delays and increased maintenance costs.

Drops of water beaded up on a gray glossy surface

02

A superhydrophobic surface treatment

AeroPel™ NPL APC400, a developing surface treatment, will work by actively preventing ice nucleation, thereby mitigating ice build-up and moisture impacts, and will protect the treated substrate from atmospheric and galvanic corrosion in harsh environments, such as arctic, humid, and marine regions.

Originally developed and tested for the military, AeroPel™ NPL APC400 has demonstrated remarkable performance. The Army Corps of Engineers Cold Regions Research and Engineering Laboratory (CRREL) revealed that AeroPel™ NPL APC400 reduced ice adhesion strength by several orders of magnitude compared to any other commercially available coating. The impressive durability observed suggests that the treatment is suitable for other anti-icing and corrosion applications, including wind turbines, bridges, railways, power transmission and other cables, and communication towers.

A person mixing Part A and Part B of the AeroPel compound in order to create the mixture

03

Why it matters

AeroPel™ NPL APC400 would address the need for efficient aircraft icing prevention, offering a solution to halt ice nucleation and protecting a wide range of industries from the operational impacts of ice accumulation. By preventing ice build-up, AeroPel™ NPL APC400 can help industries avoid the significant costs associated with repairs, delays, damages, and compensations.

AeroPel APC is being developed to mitigate aircraft icing.

See the difference that AeroPel makes.

At a glance

In testing, AeroPel™ NPL APC400 has shown that it would...

  • Cure in 24 (20°C) or 4 hours (75°C)
  • Is functional at thicknesses of 0.5mil (12.5µm) post-curing
  • Offer <5% change of thermal diffusivity for underlying substrate
  • Ice adhesion strength is <10kPa, compared to bare aluminum ice adhesion which is >1200kPa

A jug of AeroPel in front of an aircraft
Commercialization

To learn more, visit the AeroPel™ website.
